MIL-C-48582B (AR)
TABLE II.
Input and output characteristics (Cont.)
TERMINALS
REQUIREMENTS
CHARACTERISTICS
Positive pulse from O to
P1-21
Target Reset
4.0
1.0 Vdc, width of
P1-25 (Ret.)
0.79
0.10 us, PRF of
20
0.2 KHz, leading edge
coincides with leading edge
of Target Clear Pulse.
Output Signals
2560M
P1-36
50% square wave, from O V
to 4.0
1.0 Vdc period (T)
P1-24 (Ret.)
of 16.384 -- 0.200 second(s)
+
Negative pulse from O to
P1-47
Carry
4.0 + 1.0 Vdc, width of
P1-24 (Ret.)
0.100 ms, T of 16.384
0.200 s when signal #2 is
applied to P1-39.
Negative pulse from O to
P1-49
Borrow
4.0 + 1.0 vdc, width of
P1-24 (Ret.)
0.100 ms, T of
16.38
0.20 sec when signal
#2 is applied to P1-41.
Test Overflow
P1-17
50% square wave, from O to
4.0
1.0 Vdc, T of
P1-25 (Ret.)
Test #1
0.024 us when
34.160
0.0
0.5 Vdc is applied to
P1-19 & P1-21.
Target Overflow
Positive pulse from O to
P1-17
4.0
1.0 Vdc, PRF of
P1-25 (Ret.)
Test #2
20.0
0.2 KHz, leading edge
is delayed variably (pulse
width oscillates between
10.0
1.0 us and 27.0
1.0 us
with respect to Target Reset;
each cycle takes 16.38
0.2 sec
between 23.0
1.0 us and
40.0
1.0 us from Target Reset
when signal #2 is applied to
P1-39, Target Reset to P1-21,
and Target Clear to P1-19 (see
Figure 1).
