MIL-C-48582B (AR)
Altitude.
3.3.3
3.3.3.1 Operating. The Target Position Board shall meet the
requirements of 3.4 and 3.5 during and after exposure to barometric
pressure encountered at 10,000 feet above sea level (20.6 inches
Hg).
3.3.3.2 Non-operating. The Target Position Board shall meet
the requirements of 3.4 and 3.5 after exposure for not less than
10 minutes to barometric pressure encountered at 40,000 feet above
sea level ( 5.5 inches Hg).
Temperature.
3.3.4
3.3.4.1 Operating. The Target Position Board shall meet the
requirements of 3.4 and 3.5 when-stabilized thermally at any
temperature between +32 degrees F and +131 degrees F.
3.3.4.2 Non-operating (storage) . The Target Position Board
shall not suffer permanent damage when subjected to the constant
temperature extremes of -60 degrees F for a period of 24 hours and
+160 degrees F for a period of 4 hours (after temperature
stabilization) , and shall meet the requirements of 3.4 and 3.5 when
returned to room ambient.
The Target Position Board
3.3.5 Humidity (non-operating
shall meet the requirements of 3.4 and 3.5 after exposure to an
atmosphere with a relative humidity in excess of 95 percent for a
period of 10 days.
3.4 Electrical.
3.4.1 Continuity. Each conductor shall be continuous elec-
trically as specified on the schematic diagram 11747200.
Resistance shall be as specified in Table I.
3.4.2 Resistance.
Resistance
TABLE 1.
TERMINALS
RESISTANCE
TO
FROM
P1-30
P1-53
1000 ohms
5%
P1-30
P1-43
5%
1000 ohms
3.5 Performance. When supplied with the inputs as specified in
Table II, the Target Position Board shall yield the outputs as
specified in Table II.
