MIL-C-48582B (AR)
2.2 Order of precedence. In the event of conflict between the
text of this specification and the references cited herein the text
of this specification shall take precedence. Nothing in this
specification, however, shall supersede applicable laws and
regulations unless a specific exemption has been obtained.
REQUIREMENTS
3.
3.1 Materials. Materials shall be in accordance with the
applicable drawings and specifications.
3.2 Components and assemblies. The components and assemblies
shall comply with all requirements specified on Drawing 11747198,
all associated drawings, and with all requirements specified in
applicable specifications and standards. Where applicable, the
Target Position Board shall meet the requirements of MIL-F-13926 as
follows:
a.
Dimensions and tolerances.
b.
Inorganic protective surface finishings.
c.
Part identification and marking.
Workmanship.
d.
3.3 Environmental service conditions.
3.3.1 Vibration. The Target Position Board shall not suffer
damage and shall meet the requirements of 3.4 and 3.5 after exposure
to sinusoidal vibrations, in each of three mutually perpendicular
axes, as follows:
Frequency Range
Amplitude
5 to 15 hertz
0.06 inches double amplitude
15 to 25 hertz
0.04 inches double amplitude
25 to 55 hertz
O.O2 inches double amplitude
frequency of vibration shall be swept logarithmically.
The
cycling time shall be 120 minutes per axis.
The
sweep rate shall be 3.75 minutes
per decade.
The
The
5-55-5 hertz sweep time is 7 minutes 35 seconds
3.3.2 Shock. The Target Position Board shall not suffer damage
and shall meet the requirements of 3.4 and 3.5 after exposure to a
total of 18 impulse shocks consisting of three shock impulses of 15
g's
11 milliseconds
half-sine wave applied in each
direction of 3 mutually perpendicular axes.
