MIL-C-48582B (AR)
TABLE V.
Test equipment list
ITEM NUMBER
DESCRIPTION
1. Ohmmeter
Range 10 to 1000 ohms, accuracy +
--
2. Power supply
0.25 Vdc regulated, ac ripple
5.00
less than 50 mv p-p, capacity 500 MA.
3. Power supply
-5.2
0.1 Vdc regulated, ac ripple
less than 50 mV p-p, 1.5A capacity.
4. Sine-Wave Generator
120 MHz
1 KHz, 700
100 mV p-p,
into a 50 ohm load.
5. Oscilloscope
Dual channel; Rise time of scope plus
probe not greater than 10 NSEC, Sweep
period less than 50 NSEC. Input
resistance: 8 megohms or greater.
6. Digital Voltmeter
0 to 10 Vdc, Accuracy 0.1%, input
impedance 10 megohms or greater.
7. Test Fixture
As specified in Fig. 3. See Table VI
for test fixture parts list.
8. Termination
500 ohms,
1%, 4 mw .
