MIL-C-60898/9 (MU)
4
PULSE GENERATOR
0.5 microsecond to 0.5 milli-
second adjustable pulse width
adjustable duty cycle from 1
to 0.5.
Adjustable
`x
amplitude from 0.1 to 20 volts
into an output impedance of
600 ohms or less. Pulse rise
and fall times, less than 0.2
microseconds each.
5.
OSCILLOSCOPE
Voltage and time accuracy and
resolution of
5 percent or
better,
Rise time: 102 nano-
seconds or less; sweep periods
from 1 microsecond to 1 second
per centimeter.
Amplitude scales
from 0.01 to 10 volts 1 centi-
meter, automatic triggering.
6,
DIGITAL
VOLT-OHMETER
Accuracy and resolution of
0.2
percent or better from 0.9 to 99
vdc and accuracy and resolution
of 1 percent or better from 1 to
100 kilohms.
Input impedance of
10 megohms or greater on all d-c
voltage scales.
7.
AMMETER
O-5 ampere with 2 percent reso-
lution and accuracy at 0.02 milli-
ampere and 1.0 amperes.
8.
RESISTORS
Two resistors, 350 ohms and
5
percent, 5 watt, each.
9.
OHMMETER
4.5 Test methods and procedures.
4.5.1 Environmental. As specified in MIL-C-6089S except the re-
quirements of 3.3.1 herein shall be verified during temperature
extremes.
.
4,5.2 Electrical tests.
.
4.5.2.1 Conditions of operation.
Unless otherwise specified all
subsequent tests will be performed with the conditions of operation
of 3.4.1 and Figure 1,
Referring to Figure 1, connect RESISTORS
R1 and R2, using the RESISTORS, Item 8 of 4.4.1.1.
7
