MIL-C-60898/9(MU)
3.
REQUIREMENTS
The
assembly shall be manufactured in
,
Fabrication,
3.1
accordance with drawing
F10554188 and drawings pertaining
thereto.
.
The assembly shall meet the
3.2 General specifications.
requirements of MIL-C-60898.
See
MIL-C-60898.
3.3
Enviromental
service
conditions.
For the condi-
Performance at temperature extremes.
3.3.1
tions of 3.3.2 of MIL-C-60898, the requirements of 3,4 shall
` be met with exceptions as specified in the following subpara-
graphs,
There shall be -8,42
0,50 vdc
Pin 19 output,
3*3*1,1
between pin 19 and pin 28.
3.3.1.2 Pin 23 output
The voltage present between pin
23 and pin 28 shall be +15.4
1.5 vdc.
3.3.1.3 Pin 9 output.
and -1.7 vdc (rather than -1.55) between
pin
12
(-)
and
pin
28 for the outputs of 3.4.4.
The voltage drop between pin 17 (+)
3.3.1.4 Pin 17 output.
and pin 28 shall be +21.0
0.5 vdc and +1.2
0.4 vdc.
3.3.1.5 Diodes, reverse current. There shall be 0.1 milli-
ampere or less between the pins specified in Table 1.
There shall be 1
0.5 vdc
3.3.1.6 Diodes, forward drop
between the pins specified in Table 11.
performance.
3.4
Electrical
The requirements of 3.4.2
3.4.1 Conditions of operation.
through 3.4.5 shall be met with the conditions shown in Figure
1, unless otherwise specified,
3.4.2 Pin 19 output. there shall be -8.42 ± 0.15 vdc between
pin 19 (-) and pin 28.
