MIL-C-60898/9(MU)
With-1.25 vdc applied between pin 12 (-)
3.4.4 Pin 9 output.
and pin 28, there shall be -21
1 vdc between pin 9 (-) and
pin 28.
With -1.55 vdc applied between pin 12 (-) and pin 28,
there shall be -0.3
0.2 vdc between pin 9 (-) and pin 28.
The voltage between pin 17(+) and pin
3.4.5 Pin 17 output.
It shall remain at +21.0
0.5
28 shall be +21.0
0.5 vdc.
vdc when the voltage shown in Figure 2 is applied between pin
The voltage shall go to +1.2
0.4 vdc when
20 (+) and pin 28.
When
+22.0
0.1 Vdc is applied between pin 20 (+) and pin 28.
the applied +22.0
0.1 vdc at pin 20 is removed the voltage
shall remain +1.2
0.4 vdc.
Figure 2
3.4.6 Diodes, reverse current.
With +28.0
0.1 vdc applied,
respectively, between each of the two pins specified in Table
I, there shall be 0.02 milliamperes or less current between
these two pins.
3.4.7 Diodes, forward drop,
With a current of 1.0
0.1
amperes applied between each of the two pins specified in
Table II, there shall be 0,9
0,3 vdc between these two pins.
4
