MIL-C-60898/4(MU)
connect channel A vertical input of OSCILLOSCOPE, item 7 of
4.4.1.1, between pin 25 (+) and pin 28 per Figure 4.
Connect
the PULSE GENERATOR to produce the pulse of Figure 2,
the OSCILLOSCOPE channel B vertical input, per Figure 4, and
verify the waveform of Figure 3.
Figure 4
Connect the PULSE GENERATOR, item 9
Capacitor C2.
4.5.2.5
of 4.4.1.1, thru the 100 OHM RESISTOR, item 8 of 4.4.1.1,
and connect channel A vertical input of OSCILLOSCOPE, item 7
Adjust
of 4.4.1.1, between pin 13 (+) and pin 28 per Figure 5.
Connect
the PULSE GENERATOR to produce the pulse of Figure 2.
the OSCILLOSCOPE channel B vertical input, per Figure 5, and
verify the waveform of Figure 3.
