MIL-T-48466B(AR)
(Copies of Government drawings required by contractors in
connection with specific acquisition functions should be obtained
from the contracting activity or as directed by the contracting
activity.)
2.2 Order of precedence.
In the event of a conflict between
t-he text of this document and the references cited herein, the
text of this document shall take precedence. Nothing in this
document, however, supersedes applicable laws and regulations
unless a specific exemption has been obtained.
3.
REQUIREMENTS
-
The Cable Test Set, herein referred to
3.1 Item definition.
as the assembly, is a portable unit used to test Ballistic
Computer, Laser Rangefinder and Tank Thermal Sight Cables by
detecting open and short-cd conductors in t-he cables.
The assembly consists of the
3.1.1 Major components list.
following major components, all of which are covered by this
specification.
Name
Drawing Number
Cable, Power
11732468
Cable, Ammo Select
11732469
Connector, Shorting
11732556
Cable, Power
11732558
Cable, Test Set
11733300
Cable, Interconnect ion
11747425
Cable, Interconnection
11747426
Cable, Interconnection
11747427
Cable, Interconnection
11747428
Connector, Shorting (CP52)
11747429
Connector, Shorting (CP53)
11747430
Connector, Shorting (CP63)
11747431
Connector, Shorting (CP55)
11747432
Connector, Shorting (CP54)
11747433
Connector, Shorting (CP64)
11747434
(see 4.6.4)
3.1.2
General
specifications.
3.1.2.1 Manufacture and inspection.
The following
provisions of MIL-F-13926 apply:
a.
Dimensions and tolerances
b.
Effect of protective coating on dimensions (Inorganic
type coatings)
Part identification and marking
Workmanship (including applicable port-ions of
MIL-STD-2000 and MIL-STD-454, Requirement 9)
3
