MIL-C-60898/11
(MU)
DIGITAL
VOLTMETER
Accuracy and resolution no
4.
less than 0.2 percent from
0.0090 to 99.0 vdc.
Input
impedance no less than 10
megohms on all voltage scales,
5.
AMMETER
0.0 to 5.0 ampere with 2
percent resolution and ac-
curacy at 0.02 ma and 1.0
ampere.
ASSORTED COMPONENTS
6.
RESISTOR
1 percent, 0.5 watt
5 kilohm
RESISTOR
5 percent, 0.5 watt
1 kilohm
RESISTOR
1 percent, 0.5 watt
10 kilohm
RESISTOR (2 ea)
5 percent, 0.5 watt
150 ohm
0.1 uf
CAPACITOR
5 percent, 50 vdc
5.0 ampere,
single
pole-double
throw
SWITCH
Variable 0.0 to
30
vdc,
0.0
to
POWER
SUPPLY
7.
1.5 amperes.
Capacitance display from 0.005
8.
CAPACITANCE
BRIDGE
uf to 100 uf, no less than 1.0
percent accuracy and resolution
in ac/dc operation.
4.5
Test
Methods
and
Procedures
As specified
in
MIL-C-60898 except the
4.5.1
Environmental.
requirements of 3.3.1
herein shall
be
verified during tempera-
ture extremes.
4.5.2
Electrical
tests
Diode
networks
4.5.2.1
4.5,2. 1.1
Connect the ASSORTED COMPONENTS,
item 6, and POWER SUPPLY, item 1 of 4.4.1.1, to the card as
Measure the dc voltage between pin 6 (+)
shown in Figure 1.
and pin 1 (-) with the DIGITAL VOLTMETER, item 4 of 4.4.1.1,
to verify conformance with the requirements of 3.4.1.1.
Connect the ASSORTED COMPONENTS,
4.5.2.1.2 Pin 12 output.
item 6, and POWER SUPPLY, item 1 of 4.4.1.1, to the card as
Measure the dc voltage between pin 12 (+)
shown in Figure 1.
and pin 1 (-) with the DIGITAL VOLTMETER, item 4 of 4.4.1.1,
to verify conformance with the requirements of 3.4.1.1.
7
