MIL-T-50332A (AR)
kVdc shall
3.5.1.5.2 STANDBY mode. A voltage of 4.3
available between J5-C(+) and J5-E(Ret) , under the following
conditions :
a.
Conditions in 3.5.1 .5.1 are met.
P2 plugged into J5.
b.
visible)
c.
Circuit breaker CB1 closed (white
for more than 20 seconds,
3.5.1.5.3 RADIATE legend and radiate mode. Radiate legend of
S5 shall be illuminated and an output pulse as described g. and
h. below shall be available between J5-E(-) and chassis ground
(E4) under the following conditions:
a.
Controls and conditions are met in accordance with
3.5.1.4 for more than 2 minutes ± 12 seconds,
(Delay period vesrifies proper operation of time
delay relay K1.)
S5 in normally open position.
b.
c.
Circuit breaker CHl
P2 plugged into J5.
d.
e.
characteristics
f.
Not greater
NLT 4.0 and NMT 5.0 kV amplitude from leading edge
h.
baseline to most positive point excluding positive
overshoot.
