MIL-T-50332A (AR
3.5.1.2 Blower motor (Bl). Blower motor Bl shall operate under
conditions stated in paragraph 3.5.1.1 and 115 Vac, 400 Hz is
applied between J8-L and J8-M.
3.5.1.3 POWER switch (S4).
legend of S4 shall be illuminated
3.5.1.3.1 OFF legend.
when S4 is in normally closed position and conditions stated in
3.5.1.1 are met.
3.5.1.3.2 STANDBY legend. STANDBY legend of power indicator
lamp S4 shall be illuminated when S4 is in normally open position,
24 Vdc is applied between J8-R(+) and J8-S (Ret) and conditions
stated in 3.5.1.1 are met.
3.5.1.4 Output voltages (Jl) . Under conditions listed in a.
through e. below, output voltages at J1 shall be as listed in
f. through j. below:
Controls and conditions in 3.5.1.3.2.
a.
Circuit breaker CB1 closed (White band not
b.
visible) .
28 Vdc ± O.1V applied between J8-A/P(+) and J8-B/N
c.
(Ret) .
33 Vdc ± O.1V applied between J8-T(-) and J8-U (Ret) .
d.
15 Vdc ± O.1V applied between J8-E(+) and J8-F (Ret) .
e.
O.1V between J1-1(+) and J1-2 (Ret)
f.
28
O.1V between J1-3(+) and J1.-2 (Ret)
28
g.
O.1V between J1-5(+) and J1-6 (Ret)
28
h.
0.1V between J1-7(-) and J1-8 (Ret)
i.
33
0 to NMT 7.4V (variable by operation of Rl) between
j.
J1-A2 (+) and J1-4 (Ret).
3.5.1.5 RADIATE/STANDBY switch (S5)
STANDBY legend of S5 shall be illumi-
3.5.1.5.1 STANDBY legend.
nated when S5 is in the normally closed position and conditions in
3.5.1.3.2 are met.
6
