MIL-T-48593B (AR)
Voltage measurements (continued)
TABLE III.
MEASURING POINTS
VOLTAGES
+1.6 Vdc
TP11-1 (+) and UUT GND 1 (-)
+15
-1.2 Vdc
TP9-2 and UUT VAR
+115 --10%, RMS, 400 HZ
+
TP9-15 (+) and UUT GND 2 (-)
+24 +0.5 Vdc
+1.6 Vdc
TP9-12 (+) and UUT GND 2 (-)
-15
-1.2 Vdc
+1.6 Vdc
TP9-6 (+) and UUT GND 2 (-)
+15
-1.2 Vdc
TP9-1 (+) and TP10-6 (-)
+24 V
RMS, 400 HZ
TP9-0 (+) and TP10-6 (-)
+24 V --
+10%, RMS, 400 HZ
3.5.3
Interconnections.
With power switch, S25, Off, the resistance measured
between the test points indicated in Table IV shall be less thah
2.5 ohms. If a modifying condition is specified, it shall be
performed prior to the resistance measurement.
TABLE IV.
Short circuit resistance measurements
TEST POINTS
MODIFYING CONDITION
TP9-7 and TP9-5
UUT PS-2 switch on
Range Ref switch in 12V Position
TP9-7 and J11-H
TP10-1
and
J1, Pins 12, 14
UUT PS-2 switch in on position
TP10-1
and
J3, Pin 35
TP10-1
and
J2, Pin 12
TP10-1
and
J11-G
TP10-2 and J3, Pin 22
UUT PS-2 switch in on position
TP10-2 and J1, Pin 16
TP10-2 and J11-F
9.
