MTL-F-81959(AS)
Warm-Up Time - The time required for the equipment to
3.3.13
warm up prior to operations shall be kept to a minimum and shall not exceed
5 minutes under standard conditions and 10 minutes at extreme service conditions.
Primary Input Power Requirements - The equipment shall be
3.3.14
put power having character-
capable of satisf
istics as defined in MIL-T-2l20O. The power required shall be of the following
type and shall not exceed the specified amounts.
AC Power, 3 Phase, 115 V, 380-420 Hz, 525 VA
Performance - The performance of the equipment shall be as
3.4
set forth below. Unless otherwise specified, these requirements shall apply
under both standard and extreme service conditions. When reduced performance
requirements for service conditions are acceptable, such variation' will be
specified.
Detail Requirements
3.5
Fixture, Cable Maintenance MX-9516/ASQ-81(V) - The equipment
3.5.1
shall meet thu following requirements:
Function - The function of the equipment is to aid removal or
3.5.1.1
installation and inspection of the tow cable on the RL-305A/ASQ-81(V) Reeling
Machine without degrading the cable.
3.5.1.2 Maximum Form Factor - 13.5 inches wide by 10.5 inches high
by 31.5 Inches long, not Including case.
3.5.1.3 Weight - The weight of the test set shall not exceed 45 pounds,
not including case.
Finish - Hard Anodize per MIL-A-8625.
3.5.1,4
3.5.1.:
Contents - The equipment shall contain the following functional
circuits or assemb ies:
(1) TorqueMotor- The equipment shall contain a D.C. torque motor
and gear train which drives the cable drum with sufficient torque
to overcome the cable undertension switch of the Reeling Machine
RL-305A/ASQ-81(V) while reeling cable out/in at the slow speed
reeling rate and at stall.
(2) Displays - The equipment shall contain a POWER ON indicator light
located adjacent to the POWER ON/OFF switch and a time totalizing
meter.
