MIL-C-70590 Control Assembly Test Panel Ts-4215/Tsm-100B: 9361261This specification covers the Control Assembly Test Panel, hereinafter referred to as the "test set," which forms a part of the Electronics System Test Set AN/TSM-100B \(see 6.1\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11


MIL-C-70590B (AR)
TABLE IV.
Test point no. 1.
POTENTIOMETER SELECT
OUTPUT VOLTAGE AT
SWITCH POSITION
CONNECTOR AND PIN
1
J23-f
2
J23-f
3
J24-F
4
J23-M
5
J23-M
6
J22-n
3.5.4.2  TEST POINT NO. 2 (TP2).  With +24.0
0.1 Vdc applied
between TEST POINT NO. 2 (TP2) and GROUND, there shall be +24.0
0.1 Vdc between the pins specified in Table V (Test point no. 2) and
GROUND when the POTENTIOMETER SELECT switch is in the position
specified in Table V.
TABLE V.
Test point no. 2.
POTENTIOMETER SELECT
OUTPUT VOLTAGE AT
SWITCH POSITION
CONNECTOR AND PIN
1
J23-U
2
J23-U
3
J24-D
4
J23-f
5
J23-f
6
J22-r
3.5.4.3 TEST POINT WIPER (TP3).  With +24.0
0.1 Vdc applied
between TEST POINT WIPER (TP3) and GROUND, there shall be +24.0
0.1 Vdc between the pins specified in Table VI (Test point wiper)
and GROUND when the POTENTIOMETER SELECT switch is in the position
specified in Table VI.
TABLE VI.
Test point wiper.
POTENTIOMETER SELECT
OUTPUT VOLTAGE AT
SWITCH POSITION
CONNECTOR AND PIN
1
J23-S
2
J23-T
3
J23-p
4
J23-P
5
J23-D
10
