MIL-C-70512(AR)
and permit positive rejection when nonconforming. Construction
shall be such as to facilitate routine calibration of test
equipment.
4.5.2.2 Test equipment. In conjunction with 4.5.2.1, the test
equipment found in Table V shall be used in the performance of the
the applicable tests of 4.6.
TABLE V.
Test equipment list
Description
Equipment
Item
3% Regulated
15 Vdc
Power supply
1.
AC ripple: Less than
Capacity:
0.350A
Power supply
15 Vdc
3%, Regulated
2.
AC ripple: Less than 1%
Capacity: 0.350A
Vertical Passband: dc to 10 Mhz
Oscilloscope
3.
Input Sensitivity: 1 mv per division
Horizontal Deflection: 0.2 usec per
-
division to 0.5 sec. per division
Ohm Meter
To measure up to 4.0K Ohms + 1%,
4.
--
continuity or infinity
4.6 Methods of inspection.
4.6.1 Environmental. Environmental tests shall be conducted
in accordance with the general requirements and test methods of
MIL-STD-810 except as specified herein. Testing equipment used in
environmental tests shall be in accordance with "Test Facilities
and Apparatus" requirements of MIL-STD-810.
4.6.1.1 Vibration. The test shall be performed as specified
in Method 514, procedure 1, Category I, as modified by 3.3.1
herein. After vibration, the assembly shall be tested as given in
the subparagraphs of 4.6.2 and 4.6.3 for compliance with 3.3.1.
4.6.1.2 Shock. This test shall be performed as specified in
Procedure I, Method 516 of MIL-STD-810 except that shock pulses
1 ms and 15 G's. The G value of each impulse shall
shall be 11
be within +10 percent when measured with a 0.2 to 250 Hz filter
and the maximum G shall occur at approximately 5 1/2 milliseconds.
After the shock impulses, the assembly shall be tested as specified
in 4.6.2 and 4.6.3 for compliance with 3.3.2.
4.6.1.3 Altitude-nonoperating and operating. This test shall
be performed as specified in Procedure II and III, Method 500 of
The operational checkout shall be as specified in
MIL-STD-810.
4.6.3 for compliance with 3.3.3.
9
